Inspiriran klasičnim Moog modularnim sintisajzerima.
Grandmother je polu-modularni analogni sintisajzer s ugrađenim arpeggiatorom, sekvencerom i opružnim reverb spremnikom. Odmah počnite svirati bez potrebe za paching-om, a zatim istražite beskonačno zvučnu igraonicu na prednjoj ploči koja se može rekonfigurirati. "Bakini" sklopovi, spring reverb i duh inspirirani su klasičnim Moog modularnim sintesajzerima, što ovaj instrument čini moćnim dodatkom Mother-32, DFAM-u ili bilo kojem Eurorack modularnom sustavu.
Grandmother je dostupan u dva različita stila: originalni raznobojni artwork prednje ploče i potpuno crno izdanje Dark Series
Snimajte i reproducirajte sekvence sa do 256 nota svaka
Dodajte bujnu, ekspanzivnu atmosferu svakom zvuku.
Istražite široku lepezu zvučnih mogućnosti kroz analognu međupovezivost.
SPECIFICATIONS
TYPE Semi-Modular Analog Synthesizer
SOUND ENGINE Analog
NUMBER OF KEYS 32 Full-Size Keys
TYPE OF KEYS Velocity-sensing (Velocity signal is not hard-wired – available via MIDI and KBD VEL OUT jack)
OTHER CONTROLLERS Pitch Bend, Mod Wheel, Variable Glide
POLYPHONY Monophonic
SOUND SOURCES 2 Oscillators with selectable Waveforms (Oscillator 2 supports Sync to Oscillator 1 plus linear FM), 1 White Noise Generator, External Input jack
VCF FILTER (LOW PASS) -24dB/Octave Moog Ladder Filter with Resonance (Self-Oscillating)
STATIC FILTER (HIGH PASS) -6dB/Octave
MOD SOURCES Modulation Oscillator (Sine, Sawtooth, Ramp, Square), S/H Output, plus Envelope and Key Tracking
ENVELOPE Four-Stage (ADSR)
ATTENUATOR Bipolar
MULT Four Parallel-wired Non-buffered Patch Points
EFFECTS Spring Reverb
ARPEGGIATOR / STEP SEQUENCER (256 Steps; three Sequence Files)
PATCH POINTS: 41 x 3.5mm front and rear panels, 21 Inputs, 16 Outputs, 4 Parallel-wired Mults.
AUDIO INPUT One 1/4” TS jack (Rear Panel)
AUDIO OUTPUT One 1/4” TRS jack for headphones or line level output (Rear Panel)
MIDI I/O 5-pin DIN In, Out, Thru; plus MIDI over USB (Rear Panel)
DIMENSIONS 23” (58.42cm) Wide x 14 1/4” (36.19cm) Deep x 5 1/2” (13.97cm) High
POWER Included Power Adapter 12V DC (positive tip), 2A, 100 to 240 Volts AC, 50/60Hz
WEIGHT 7.25kg
